Allen-Bradley | 5069-IY4 | ControlLogix 5069 Compact I/O

Product Description: Allen-Bradley 5069-IY4

The Allen-Bradley 5069-IY4 is a digital output module designed for use with the ControlLogix 5069 Compact I/O system. This module provides 4 isolated transistor outputs suitable for switching DC loads in industrial automation systems. It offers high-speed switching capabilities and flexible wiring options, making it ideal for controlling actuators, solenoids, and indicator lights in compact control panels.

Product Type

• Digital Output Module
• Series: ControlLogix 5069 Compact I/O
• Outputs: 4 transistor outputs (sourcing)
• Output Type: Isolated, sourcing transistor outputs

Key Features

• 4 digital transistor outputs, 24V DC sourcing
• Individually isolated outputs for enhanced noise immunity and protection
• High-speed output switching for fast device control
• LED status indicators for each output channel
• Compact form factor for space-saving installation
• Compatible with ControlLogix 5069 Compact I/O chassis
• Supports hot-swappable installation
• DIN rail or panel mountable

Technical Specifications

• Output Voltage: 24V DC nominal
• Output Current per Channel: 0.5 A continuous
• Total Module Current: 2 A maximum
• Isolation Voltage: 500 V AC (output to backplane)
• Switching Frequency: Up to 10 kHz
• Backplane Current Consumption: Approximately 200 mA at 5V DC
• Operating Temperature: 0°C to 60°C
• Certifications: UL, CE, cUL, RoHS

Application Areas

• Machine automation and control
• Robotics and material handling
• Process control systems
• Packaging and assembly lines
• Indicator and signal control

Advantages

• Reliable and fast switching outputs for various industrial applications
• Individually isolated channels improve system robustness
• Easy integration within ControlLogix 5069 systems
• LED indicators simplify troubleshooting and maintenance
• Compact and modular design facilitates scalable solutions
