Product Description: Allen-Bradley 2711P-RN1
The Allen-Bradley 2711P-RN1 is an RS-232 DF1 communication module used with PanelView Plus terminals to enable serial communication with PLC controllers. Designed as a plug-in accessory, this module provides point-to-point serial connectivity using the DF1 protocol. It is commonly used in systems where Ethernet is not available or where integration with legacy PLCs is required.
Key Features
- Provides RS-232 DF1 serial communication capability
- Enables point-to-point connection with PLC-5, SLC 500, and MicroLogix controllers
- Designed for use with PanelView Plus 400 to 1500 terminals
- Easy installation via the communication slot on the logic module
- DF1 full-duplex protocol support
- Compact and durable for industrial use
Technical Specifications
- Communication Protocol: DF1 (RS-232, full duplex)
- Connector Type: 9-pin D-shell (D-sub) male
- Compatible Terminals: PanelView Plus (400 to 1500)
- Baud Rate: Configurable up to 19.2 kbps
- Installation Method: Plug-in to logic module communication port
- Power Supply: Powered via terminal’s logic module
- Operating Temperature: 0 to 55 °C (32 to 131 °F)
Application Areas
- Legacy PLC integration using DF1 serial communication
- Point-to-point HMI connections for standalone equipment
- Machine-level control panels with serial interface requirements
- Compact automation systems without Ethernet infrastructure
- Small-to-medium-sized industrial machines and OEM equipment
Advantages
- Enables reliable DF1 serial communication without complex networking
- Facilitates easy integration with existing Allen-Bradley controllers
- Straightforward configuration through FactoryTalk View ME
- Low-cost connectivity solution for non-Ethernet systems
- Compact design with plug-and-play compatibility
