Allen-Bradley | 2711-T10C9 | PanelView 1000 Standard

Product Description: Allen-Bradley 2711-T10C9

The Allen-Bradley 2711-T10C9 is a 10.1-inch color touchscreen operator interface terminal from the PanelView 1000 Standard series. Designed for industrial automation applications, it provides reliable monitoring and control capabilities. The terminal features a resistive touchscreen and supports Data Highway Plus (DH+) and RS-232 communication protocols, facilitating integration with various control systems.

Key Features

• 10.1-inch color display with 640 x 480 pixel resolution
• Analog resistive touchscreen with 384 touch cells (24 columns x 16 rows)
• Supports Data Highway Plus (DH+) and RS-232 (printer) communication ports
• 1008 KB application memory and 256 KB RAM
• Backlight with 100,000-hour lifespan
• Operates on 85–264V AC power supply
• NEMA Type 12/13 or 4X enclosure rating for indoor use
• Operating temperature range: 0 to 55°C (32 to 131°F)

Technical Specifications

• Display Area: 211 x 158 mm (8.3 x 6.2 inches)
• Touch Cell Size: 26 x 30 pixels
• Input Power: 85–264V AC, 47–63 Hz
• Heat Dissipation: 39 W (132 BTU/hr)
• Dimensions (HxWxD): 282 x 370 x 112 mm (11.11 x 14.58 x 4.40 inches)
• Memory: 1008 KB application memory, 256 KB RAM
• Communication Ports: DH+ and RS-232 (printer)
• Enclosure Rating: NEMA Type 12/13 or 4X (indoor use)
• Operating Temperature: 0 to 55°C (32 to 131°F)

Application Areas

• Industrial automation and process control
• Manufacturing execution systems (MES)
• Packaging and material handling equipment
• Food and beverage processing
• Pharmaceutical and chemical industries
• Water and wastewater treatment facilities

Advantages

• Reliable and durable design suitable for industrial environments
• Easy integration with legacy Allen-Bradley PLCs via DH+ communication
• User-friendly touchscreen interface for efficient operation
• Long-lasting backlight reduces maintenance requirements
• Compact design conserves panel space
