Allen-Bradley | 2198-P070 | Kinetix 5700

Product Description: Allen-Bradley 2198-P070

The Allen-Bradley 2198-P070 is a 70 kW power supply module used within the Kinetix 5700 servo drive platform. Designed to deliver high-performance motion control in large and complex automation systems, this power module enables efficient power conversion and distribution to connected axis modules. It supports integration with Rockwell Automation’s Integrated Architecture system for simplified design and high-speed communication.

Key Features

• 70 kW continuous output power capacity
• Regenerative bus supply capabilities
• Designed for multi-axis systems with shared bus architecture
• Integrated safety features including Safe Torque-Off (STO)
• High-speed communication via EtherNet/IP
• Supports Logix-based configuration and diagnostics in Studio 5000
• Modular design for scalable machine architectures

Technical Specifications

• Input Voltage: 3-phase, 380–480V AC
• Continuous Output Power: 70 kW
• Compatible Bus Supply: Shared DC bus for multiple axis modules
• Power Supply Type: Regenerative or non-regenerative (depending on system configuration)
• Enclosure Type: Open Type
• Mounting: Panel Mount
• Dimensions (HxWxD): approx. 435 x 200 x 280 mm
• Weight: approx. 14.0 kg

Application Areas

• High-performance packaging machinery
• Automotive assembly and robotics
• Print and web handling systems
• Material forming and cutting machines
• Multi-axis coordinated motion systems

Advantages

• Scalable solution for demanding motion applications
• Reduces wiring and panel space with shared bus architecture
• High energy efficiency through regeneration
• Seamless integration with Rockwell’s Logix controllers
• Simplifies commissioning and maintenance with Studio 5000 tools
