Product Description: Allen-Bradley 2094-BC02-M02-M

The Allen-Bradley 2094-BC02-M02-M is an integrated converter/inverter module from the Kinetix 6000 multi-axis servo drive system. It provides a 460V AC input and supplies power and motion control for two servo axes. With a continuous output current of 11.1 A per axis, this module combines power conversion and dual-axis control into a single space-saving unit. It includes medium-inertia motor support and integrates into Logix-based motion control architectures via SERCOS interface.

Key Features

• Combines converter and dual-axis inverter in one module
• Continuous output current: 11.1 A per axis
• Peak output current: 22.2 A per axis
• 460V AC input voltage (3-phase)
• Internal shunt resistor and bus capacitor support
• Supports Safe Torque-Off (STO) with proper configuration
• Compatible with Kinetix 6000 shared DC bus architecture
• Communication via SERCOS fiber-optic interface
• Supports coordinated motion and high-performance axis control

Technical Specifications

• Input Voltage: 3-phase, 324–528V AC, 50/60 Hz
• Output Current:
  • Continuous: 11.1 A per axis
• Converter Type: Common Bus
• Axis Count: 2
• Communication: SERCOS interface (via fiber optic)
• Enclosure Type: Open type (IP20)
• Mounting: Panel mount via integrated backplane/power rail
• Operating Temperature: 0°C to +50°C
• Dimensions (approx.): 380 mm H x 140 mm W x 230 mm D
• Certifications: UL, CE, cULus, TUV, RoHS

Application Areas

• Multi- axis coordinated motion systems
• Robotics and pick-and-place machines
• Printing and packaging lines
• High-speed material handling equipment
• Industrial automation systems with space and wiring constraints

Advantages

• Combines power and motion in one compact unit
• Reduces wiring and panel complexity
• Supports dual-axis control from a single module
• Seamless integration with Rockwell Logix platforms
• Scalable for complex multi-axis configurations
