Allen-Bradley | 100-C12D10 | 100-C Serie

Product Description: Allen-Bradley 100-C12D10

The Allen-Bradley 100-C12D10 is a compact 3-pole IEC contactor rated for 12A (AC-3 duty), equipped with a 24V DC electronic coil and one integrated Normally Open (1 NO) auxiliary contact. Designed for controlling small motors and resistive loads, this contactor is ideal for industrial applications requiring energy-efficient operation, space-saving design, and dependable performance.

Key Features

• 3-pole contactor with 12A AC-3 current rating
• 24V DC electronic coil with low inrush and silent operation
• Integrated 1 NO auxiliary contact for additional control flexibility
• DIN rail or panel mounting options
• Compact and finger-safe terminal design
• Global certifications for industrial applications
• High electrical and mechanical durability

Technical Specifications

• Rated Operational Current (Ie): 12 A (AC-3, 400V)
• Rated Operational Voltage: Up to 690V AC
• Power Rating: Up to 5.5 kW (AC-3, 400V)
• Coil Voltage: 24V DC (electronic)
• Auxiliary Contacts: 1 Normally Open (1 NO)
• Electrical Life: 1 million operations (AC-3 duty)
• Mechanical Life: 10 million operations
• Mounting: DIN rail or screw mount
• Operating Temperature: -25°C to +60°C
• Certifications: UL Listed, CSA Certified, CE Marked, IEC/EN 60947-4-1

Application Areas

• Motor starters for pumps, fans, and compressors
• HVAC systems and automated equipment
• General-purpose industrial switching
• Control panels for OEM and machine builders
• Environments requiring compact and reliable motor control

Advantages

• Energy-efficient and quiet DC coil operation
• Integrated auxiliary contact reduces need for separate components
• Compact size allows for efficient panel layout
• Reliable performance with long service life
• Fully certified for global industrial use
