PowerFlex 750 (20-750 Series) | Allen-Bradley | 20-750-2262D-2R /A PowerFlex 750 115V I/O Module 207502262D2R

Product Description: Allen-Bradley 20-750-2262D-2R

The Allen-Bradley 20-750-2262D-2R is a Dual-Port EtherNet/IP communication adapter designed for the PowerFlex 750 series drives, including PowerFlex 753 and PowerFlex 755. This module provides high- performance, real-time EtherNet/IP connectivity for integration into networked industrial systems. It includes dual Ethernet ports to support Device Level Ring (DLR) topologies and offers two relay outputs for digital status signaling or event-driven control.

Key Features

• Dual Ethernet ports for linear, star, or Device Level Ring (DLR) topologies
• Supports EtherNet/IP protocol for real-time data exchange
• 2 integrated relay outputs for drive status or alarms
• Compatible with PowerFlex 753 and PowerFlex 755 drives
• Built-in diagnostic LEDs for link and activity status
• Mounts into the communication bay of PowerFlex 750 drives
• Enhances flexibility and integration in modern Ethernet-based control systems

Technical Specifications

• Network Protocol: EtherNet/IP
• Ethernet Ports: 2 x RJ45, 10/100 Mbps, auto-negotiating
• Relay Outputs: 2 Form C (SPDT) relays, configurable for various events
• Topology Support: Linear, Star, Device Level Ring (DLR)
• Configuration: Via Studio 5000 or HIM module
• Operating Temperature: 0°C to 60°C
• Power Supply: Powered directly from the drive
• Mounting: Internal to PowerFlex 750-series drive communication bay
• Certifications: UL Listed, CE, CSA, EtherNet/IP Conformance Tested, RoHS

Application Areas

• Networked drive systems in manufacturing and process industries
• High-availability control architectures using DLR topologies
• Material handling, pumping, and fan systems
• OEM machine designs requiring integrated Ethernet communication
• Systems with SCADA, HMI, and controller integration over EtherNet/IP

Advantages

• Simplifies integration of PowerFlex 750 drives into Ethernet networks
• Dual-port DLR support enhances network reliability
• Relay outputs enable external device signaling or alarm control
• Easy to configure using Rockwell Automation tools
• Reduces wiring and improves system diagnostics in modern automation systems
